2x8 HDMI 2.1 Splitter - 48Gbps with Scaler and Audio De-Embedding

  • Article No. PT-SP-HD28-48G
  • EAN 4251364745199
  • Für weitere Informationen bitte einloggen.
  • Your Price *

All prices excl. value added tax

PureTools
RESOURCES
Description Features Logistics Dokumente
Description
Zurück
8K60 / 4K120 Multi Function HDMI Switcher /Splitter

48Gbps all in one Switcher / Splitter
This 2x8 HDMI 2.1 Splitter / Switcher single-unit solution offers comprehensive 48Gbps HDMI signal handling versatility for any professional AV installation. Reccomenmded for projects running anything from legacy 1080p, up to modern 4K 120Hz or full 8K installations.

  • Upto 48Gbps: Full support for 8K 60Hz 4:2:0, 8K 30Hz 4:4:4, 5K 60Hz 4:4:4 and 4K 120Hz 4:4:4 with HDCP 2.3 compatibility.
  • 12 Bit Colour Depth: Immerse yourself in stunning visuals with HDR10+, Dolby Vision, RGB, YCbCr 4:4:4 / 4:2:2, and YUV 4:2:0 support.
  • Dual Switchable Inputs: Easily switch between two inputs with auto switching, CEC button, and RS232 control for seamless operation.
  • Audio De-embedding: Enjoy digital SPDIF and analogue 5 pin Phoenix audio de-embedding for a complete audio experience.
  • Advanced Features: Benefit from comprehensive EDID options, HDCP 1.4 / 2.3 handshake management, CEC On/Off switch, and 8K to 4K and 8K/4K to 1080p downscaling capabilities.
For total Video Management - Switch to PureTools
The HDMI Splitters from the PureTools range offer cutting edge signal distribution and intelligent signal management. Designed to be a single box solution for amplifying and distributing video to multiple displays of all versions of HDMI up to and including HDMI 2.1. Most models boast additioanl secondary signal control such as digital and analogue audio extraction, or CEC, RS232 control, making them the professional choice for AV installation..

The PureTools objective is to provide flawless signal reproduction, manipulation and conversion of all major signal transmission standards, including HDMI, DisplayPort, USB, HDBaseT, Ethernet and many more. All traditional AV products such as matrices, switchers, splitters, converters and extenders are represented, however they are enhanced with unique innovations and intelligent design choices you won’t find anywhere else. A comprehensive toolbox of high-quality reliable audio/ video products for every aspect of the install.
  • Everyday heroes - cost-effective work-horse products for use on every install
  • Innovative problem solvers – test tools, dongles and converters that deliver solutions to your problems
  • Complete AV systems - Feature-rich solution kits, that fulfil every need of the client

The aim of the PureTools series is to equip the installer and the end client with the perfect tool for every job without compromising on quality or breaking the bank. For true “Install and Forget” performance, look no further than the PureTools series.

Features
Zurück
Features
48Gbps FRL - 8K 60Hz 4:2:0 12bit / 4K 120Hz 4:4:4 12bit, with full support for VRR, ALLM, QMS, QFT, SBTM
12bit colour depth supporting HDR10+, Dolby Vision, RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0
Dual switchable inputs with Auto switching, CEC button and RS232 control
Digital SPDIF and analogue 5-pin Phoenix audio de-embedding
Comprehensive EDID management and HDCP 1.4 / 2.3 handshake management CEC On/Off switch, 8K to 4K and 8K/4K to 1080p downscaling
Logistics
Zurück
Logistics Information
Product 1. Net Weight in Kg 1,29
Product 1. Gross Weight in Kg 1,63
Product 1. Length in cm 36
Product 1. Width in cm 20
Product 1. Height in cm 6
Packaging 1. Length in cm 37
Packaging 1. Width in cm 21
Packaging 1. Height in cm 6,5
Master Carton Length in cm 46
Master Carton Width in cm 41
Master Carton Height in cm 37
Product Information
Europeans Customs Tariff Nr. 85176200000
Country of Origin China
Packaging Material Plastic/Paper
VPE Information
Master Packaging Unit (pcs) 10
Dokumente
Zurück
Dokumente "2x8 HDMI 2.1 Splitter - 48Gbps with Scaler and Audio De-Embedding"
